Packard 45460 Multi-Horsepower Direct Drive Blower Motor, Open Enclosure, 1/2 to 1/6 hp, 115 VAC, 60 Hz, 1 ph, 48 Frame, 1075 rpm Speed, Hole in Shell/Ring/Thru-Bolt Mount
Part #: PACK45460
MFG #: 45460
Packard Direct Drive Blower Motor, Multi-Horsepower, Fan & Blower Motors Application, 1/2 to 1/6 hp, 115 VAC, 5.8/5.1/3.5/3.2/2.2 A, 60 Hz Frequency, 1 ph, 1075 rpm Speed, 4 Speed, Open Enclosure, 48 Frame, 1/2 in Dia x 5 in L Shaft, Reversible Rotation, Sleeve Bearing, Hole in Shell/Ring/Thru-Bolt Mounting, Insulation Class: Class B, 5-5/8 in Dia Dimensions,
Brand : Packard
Amperage Rating : 5.8/5.1/3.5/3.2/2.2 A
Application Type : Fan & Blower Motors
Bearing Type : Sleeve
Country of Origin : CN
Dimensions : 5-5/8 in Dia
Features
- Multiple capacitor or speed combinations
- Continuous duty, air-over
- Mounting rings, thru-bolts and holes in shell
- Electrically reversible rotation
- Automatic overload protection
- 7.5 uF at 370 VAC capacitor required
