Grundfos 96860172 MQ Series Pressure Booster Pump, 13.7 gpm Flow Rate, 1 in NPT Inlet x 1 in NPT Outlet, 110 to 120 VAC, 1 ph Phase
GRUMQ335
MFG #: 96860172
- Amperage Rating: 8 A
- Flow Rate: 13.7 gpm
- Frequency Rating: 60 Hz
- Impeller Type: PPO + 20% Glass Fiber-PTFE
- Inlet Size: 1 in NPT
- Manufacturer Name: Grundfos
- Material: POM + 25% Glass Fiber
- Maximum Head: 114.8 ft
- Maximum Pressure: 109 psi
- Outlet Size: 1 in NPT
- Phase: 1 ph
- Power Rating: 1.2 hp
- Series: MQ Series, MQ3-35 A-B-A-BVBP
- Temperature Rating: 32 to 113 deg F Ambient
- Voltage Rating: 110 to 120 VAC
- Features and More
Features
- MQ is a compact water supply system designed for domestic, agricultural and horticultural applications
- All-in-one pressure booster unit
- Easy installation
- Easy to operate
- Self-priming
- Dry-running protection
- Low noise
- Maintenance-free
- Standard pump version
- Standard material
- Bellow rubber shaft seal, Ceramic rotating seal face, Carbon resin-impregnated stationary seal face and NBR (nitrile rubber) secondary seal
- https://www.youtube.com/watch?v=6crT7RIjxh8
Includes
- Motor
Standards/Approvals/Certifications
- CSAcus Certified
Warranty
- 2 Years
